Id |
Название продукта |
Описание |
01 |
019300301 |
1930-front housing p-cd01 |
02 |
019300302 |
1930-greaser p-02cd/ncd/hcd |
03 |
019300303 |
1930-bushing p-cd03 |
04 |
019300304 |
1930-gasket p-cd04 |
05 |
019300305 |
1930-retainer ring p-05cd/ncd/hcd |
06 |
019300306 |
O-Ring |
07 |
019300307 |
1930-anvil p-cd07 |
08 |
019300308 |
1930-hammer pin (2 pcs) p-cd08 |
09 |
019300309 |
1930-steell ball (4 pcs) p-09cd/ncd/hcd |
10 |
019300310 |
1930-hammer (2 pcs) p-cd10 |
11 |
019300311 |
1930-hammer cage p-cd11 |
12 |
019300312 |
1930-o-ring p-cd12 |
13 |
019300313 |
1930-ball bearing p-cd13 |
14 |
019300314 |
1930-oil seal p-14cd/ncd/hcd |
15 |
019300315 |
1930-front end plate p-cd15 |
16 |
019300316 |
1930-rotor p-cd16 |
17 |
019300317 |
1930-vanes set (6 pcs) p-cd17 |
18 |
019300318 |
1930-cylinder p-cd18 |
19 |
019300319 |
1930-rear end plate set p-cd19 |
20 |
019300320 |
1930-ring p-cd20 |
21 |
019300321 |
1930-ball bearing p-21cd/ncd/hcd |
22 |
019300322 |
1930-snap ring p-22cd/ncd/hcd |
23 |
019300323 |
1930-o-ring p-cd23 |
24 |
019300324 |
1930-reverse valve p-cd24 |
25 |
019300325 |
1930-spring p-25cd/ncd/hcd |
26 |
019300326 |
1930-steel ball p-26cd/ncd/hcd |
27 |
019300327 |
1930-housing p-cd27 |
28 |
019300328 |
1930-reverse lever p-cd28 |
29 |
019300329 |
1930-screw p-cd29 |
30 |
019300330 |
1930-collar p-cd30 |
31 |
019300331 |
1930-screw (4 pcs) p-cd31 |
32 |
019300332 |
1930-trigger p-cd32 |
33 |
019300333 |
1930-o-ring p-cd33 |
34 |
019300334 |
1930-spring pin p-cd34 |
35 |
019300335 |
1930-spring pin p-cd35 |
36 |
019300336 |
1930-bushing p-cd36 |
37 |
019300337 |
Valve Stem |
38 |
019300338 |
1930-spring p-cd38 |
39 |
019300339 |
1930-exhaust deflector p-cd39 |
40 |
019300340 |
1930-air inlet 1/2" p-cd40 |
41 |
019300341 |
1930-cap screw p-41cd/ncd/hcd |
42 |
019300342 |
1930-handle ring p-42cd/ncd/hcd |
43 |
019300343 |
1930-handle p-43cd/ncd/hcd |
45 |
019300345 |
1930-spring pin (2 pcs) p-cd45 |
46 |
019300346 |
1930-gasket p-cd46 |
47 |
019300347 |
1930-washer p-cd47 |
48 |
019300348 |
1930-insert recoil (4 pcs)1936 p-cd48 |
49 |
019300349 |
1930-o-ring (2 pcs) p-cd49 |
