Id |
Изображение |
Название продукта |
Art. |
Описание |
N.25-26-27-28-29-42-80 |
|
019360017 |
1936/7R |
ремонтный комплект для 1936/7 |
15 |
|
019360615 |
1936 7P-15 |
1936-7P-15-rear handle |
16 |
|
019360616 |
1936 7P-16 |
1936-7P-16-air inlet |
17 |
|
019360617 |
1936 7P-17 |
1936-7P-17-bushing |
18 |
|
019360618 |
1936 7P-18 |
1936-7P-18-lever |
19 |
|
019360619 |
1936 7P-19 |
1936-7P-19-housing ring |
20 |
|
019360620 |
1936 7P-20 |
1936-7P-20-lever unlocking |
21 |
|
019360621 |
1936 7P-21 |
1936-7P-21-filter |
22 |
|
019360622 |
1936 7P-22 |
1936-7P-22-bushing |
23 |
|
019360623 |
1936 7P-23 |
1936-7P-23-stem valve |
24 |
|
019360624 |
1936 7P-24 |
1936-7P-24-lever pin |
25 |
|
019360625 |
1936 7P-25 |
1936-7P-25-o-ring |
26 |
|
019360626 |
1936 7P-26 |
1936-7P-26-spring |
27 |
|
019360627 |
1936 7P-27 |
1936-7P-27-conical spring |
28 |
|
019360628 |
1936 7P-28 |
1936-7P-28-snap ring |
29 |
|
019360629 |
1936 7P-29 |
1936-7P-29-o-ring (2 pcs.) |
30 |
|
019360630 |
1936 7P-30 |
1936-7P-30-bushing |
31 |
|
019360631 |
1936 7P-31 |
1936-7P-31-valve |
32 |
|
019360632 |
1936 7P-32 |
1936-7P-32-cage |
33 |
|
019360633 |
1936 7P-33 |
1936-7P-33-weigth (2 pcs.) |
34 |
|
019360634 |
1936 7P-34 |
1936-7P-34-pin (2 pcs.) |
35 |
|
019360635 |
1936 7P-35 |
1936-7P-35-shim |
36 |
|
019360636 |
1936 7P-36 |
1936-7P-36-spring |
37 |
|
019360637 |
1936 7P-37 |
1936-7P-37-pin |
38 |
|
019360638 |
1936 7P-38 |
1936-7P-38-side exhaust |
41 |
|
019360641 |
1936 7P-41 |
1936-7P-41-allen screw |
42 |
|
019360642 |
1936 7P-42 |
1936-7P-42-o-ring |
47 |
|
019360647 |
1936 7P-47 |
1936-7P-47-angle housing |
48 |
|
019360648 |
1936 7P-48 |
1936-7P-48-rear end plate |
49 |
|
019360649 |
1936 7P-49 |
1936-7P-49-cylinder |
50 |
|
019360650 |
1936 7P-50 |
1936-7P-50-rotor |
51 |
|
019360651 |
1936 7P-51 |
1936-7P-51-vanes set (4 pcs.) |
52 |
|
019360652 |
1936 7P-52 |
1936-7P-52-front end plate |
53 |
|
019360653 |
1936 7P-53 |
1936-7P-53-spacer |
54 |
|
019360654 |
1936 7P-54 |
1936-7P-54-cover washer |
55 |
|
019360655 |
1936 7P-55 |
1936-7P-55-driving gear |
56 |
|
019360656 |
1936 7P-56 |
1936-7P-56-driven gear |
57 |
|
019360657 |
1936 7P-57 |
1936-7P-57-cover ring |
58 |
|
019360658 |
1936 7P-58 |
1936-7P-58-handle |
59 |
|
019360659 |
1936 7P-59 |
1936-7P-59-screw |
60 |
|
019360660 |
1936 7P-60 |
1936-7P-60-nut |
61 |
|
019360661 |
1936 7P-61 |
1936-7P-61-greaser |
62 |
|
019360662 |
1936 7P-62 |
1936-7P-62-elastic washer |
63 |
|
019360663 |
1936 7P-63 |
1936-7P-63-washer |
64 |
|
019360664 |
1936 7P-64 |
1936-7P-64-retainer ring |
65 |
|
019360665 |
1936 7P-65 |
1936-7P-65-pin |
67 |
|
019360667 |
1936 7P-67 |
1936-7P-67-key |
68 |
|
019360668 |
1936 7P-68 |
1936-7P-68-spacer |
69 |
|
019360669 |
1936 7P-69 |
1936-7P-69-spacer |
70 |
|
019360670 |
1936 7P-70 |
1936-7P-70-shim adjusting |
71 |
|
019360671 |
1936 7P-71 |
1936-7P-71-shim adjusting |
72 |
|
019360672 |
1936 7P-72 |
1936-7P-72-elastic washer |
73 |
|
019360673 |
1936 7P-73 |
1936-7P-73-threaded insert |
74 |
|
019360674 |
1936 7P-74 |
1936-7P-74-snap ring |
75 |
|
019360675 |
1936 7P-75 |
1936-7P-75-ball bearing |
76 |
|
019360676 |
1936 7P-76 |
Ball Bearing |
77 |
|
019360677 |
1936 7P-77 |
1936-7P-77-ball bearing |
78 |
|
019360678 |
1936 7P-78 |
1936-7P-78-ball bearing |
79 |
|
019360679 |
1936 7P-79 |
1936-7P-79-felt washer |
80 |
|
019360680 |
1936 7P-80 |
1936-7P-80-o-ring |
88 |
|
019360688 |
1936 7P-88 |
1936-7P-88-5/8 11 unc wheel spindle |
89 |
|
019360689 |
1936 7P-89 |
1936-7P-89-disc holder |
90 |
|
019360690 |
1936 7P-90 |
1936-7P-90-guard (part. 59,60,62) |
91 |
|
019360691 |
1936 7P-91 |
1936-7P-91-wheel nut flange |
92 |
|
019360692 |
1936 7P-92 |
1936-7P-92-allen screw |
93 |
|
019360693 |
1936 7P-93 |
1936-7P-93-pin |
94 |
|
019360694 |
1936 7P-94 |
1936-7P-94-retainer ring |
99 |
|
019360699 |
1936 7P-99 |
1936-7P-99-spanner |
100 |
|
019360700 |
1936 7P-00 |
1936-7P-00-spanner |
